Supply China Making Hydraulic Piston Pump Vane Pump Gear Pumps (CY/A2F/A10VSO/VQ/PFE etc)
Pin Type Vane Pump PFE fixed displacement vane pumps are high-performance industrial pumps offering remarkable features:;
Basic Info.
Model NO. | A10VSO140 |
Roating Speed Range | 600-2800rpm |
Displacement Range | 16.5-150ml/Rev |
Transport Package | in Carton or Plywood Case |
Trademark | hyphen |
Origin | Jiangsu, China |
HS Code | 8413603101 |
Production Capacity | 500000PCS/Year |
Product Description
Pin Type Vane Pump
PFE fixed displacement vane pumps are
high-performance industrial pumps offering remarkable features:
excellent reliability and easy servicing
long working life, over 106 cycles
low noise level, as shown on diagram
suitable for hydraulic oils or synthetic fluids
high technology in design and
manufacturing
maximum versatility for any use
This pump including single and double ,they can be used in engineering machinery,mining machinery ,light industry , chemical industry and agriculture machinery etc.
Modle | Displacement(ml/r) | Ratedpressure(Mpa) | Output flow(L/min) | Drivingpower(kW) | Speed range(r/min) | Weight(kg) | Port size | |
Intel | Outlet | |||||||
PFE-31016 | 16.5 | 21 | 16 | 6.5 | 800~2800 | 9 | 1 1/4" | 3/4" |
PFE-31022 | 21.6 | 23 | 10 | |||||
PFE-31028 | 28.1 | 33 | 14 | |||||
PFE-31036 | 35.6 | 43 | 18 | |||||
PFE-31044 | 43.7 | 55 | 23 | |||||
PFE-41029 | 29.3 | 21 | 34 | 14 | 700~2500 | 14 | 1 1/2" | 1" |
PFE-41037 | 36.6 | 45 | 18 | |||||
PFE-41045 | 45.0 | 57 | 23 | |||||
PFE-41056 | 55.8 | 72 | 30 | |||||
PFE-41070 | 69.9 | 91 | 37 | |||||
PFE-41085 | 85.3 | 114 | 47 | 700~2000 | ||||
PFE-51090 | 90.0 | 21 | 114 | 47 | 600~2200 | 25.5 | 2" | 1 1/4" |
PFE-51110 | 109.6 | 141 | 58 | |||||
PFE-51129 | 129.2 | 168 | 69 | |||||
PFE-51150 | 150.2 | 197 | 80 | 600~1800 | ||||
